型号 Item No. |
尺寸 DIMENSION | |||||
|
E |
φD |
φd |
W |
B |
L |
|
|
LYF10-5 |
5.3 |
8.0 |
5.0 |
11.5 |
9.0 |
28.0 |
|
LYF10-6 |
6.5 |
8.0 |
5.0 |
11.5 |
9.0 |
28.0 |
|
LYF10-8 |
8.4 |
8.0 |
5.0 |
13.5 |
9.0 |
32.0 |
|
LYF10-10 |
10.5 |
8.0 |
5.0 |
16.0 |
9.0 |
34.0 |
|
LYF16-6 |
6.5 |
9.0 |
6.0 |
13.0 |
10.0 |
33.0 |
|
LYF16-8 |
8.4 |
9.0 |
6.0 |
13.0 |
10.0 |
33.0 |
|
LYF16-10 |
10.5 |
9.0 |
6.0 |
16.0 |
10.0 |
38.0 |
|
LYF16-12 |
13.0 |
9.0 |
6.0 |
22.0 |
10.0 |
47.0 |
|
LYF25-6 |
6.5 |
11.0 |
8.0 |
16.0 |
11.0 |
37.0 |
|
LYF25-8 |
8.4 |
11.0 |
8.0 |
16.0 |
11.0 |
38.0 |
|
LYF25-10 |
10.5 |
11.0 |
8.0 |
17.0 |
11.0 |
42.0 |
|
LYF25-12 |
13.0 |
11.0 |
8.0 |
22.0 |
11.0 |
47.0 |
|
LYF35-6 |
6.5 |
13.0 |
9.0 |
18.0 |
14.0 |
44.0 |
|
LYF35-8 |
8.4 |
13.0 |
9.0 |
18.0 |
14.0 |
44.0 |
|
LYF35-10 |
10.5 |
13.0 |
9.0 |
18.0 |
14.0 |
44.0 |
|
LYF35-12 |
13.0 |
13.0 |
9.0 |
22.0 |
14.0 |
52.0 |
|
LYF50-6 |
6.5 |
14.5 |
11.0 |
21.0 |
17.0 |
50.0 |
|
LYF50-8 |
8.4 |
14.5 |
11.0 |
21.0 |
17.0 |
50.0 |
|
LYF50-10 |
10.5 |
14.5 |
11.0 |
21.0 |
17.0 |
50.0 |
|
LYF50-12 |
13.0 |
14.5 |
11.0 |
21.0 |
17.0 |
53.0 |
|
LYF70-6 |
6.5 |
17.0 |
13.0 |
25.0 |
20.0 |
55.0 |
|
LYF70-8 |
8.4 |
17.0 |
13.0 |
25.0 |
20.0 |
55.0 |
|
LYF70-10 |
10.5 |
17.0 |
13.0 |
25.0 |
20.0 |
55.0 |
|
LYF70-12 |
13.0 |
17.0 |
13.0 |
25.0 |
20.0 |
58.0 |
|
LYF70-16 |
17.0 |
17.0 |
13.0 |
28.0 |
20.0 |
64.0 |
|
LYF95-8 |
8.4 |
20.0 |
15.0 |
29.0 |
23.0 |
69.0 |
|
LYF95-10 |
10.5 |
20.0 |
15.0 |
29.0 |
23.0 |
69.0 |
|
LYF95-12 |
13.0 |
20.0 |
15.0 |
29.0 |
23.0 |
69.0 |
|
LYF95-16 |
17.0 |
20.0 |
15.0 |
29.0 |
23.0 |
69.0 |
|
LYF120-10 |
10.5 |
22.0 |
17.0 |
32.0 |
25.0 |
73.0 |
|
LYF120-12 |
13.0 |
22.0 |
17.0 |
32.0 |
25.0 |
73.0 |
|
LYF120-16 |
17.0 |
22.0 |
17.0 |
32.0 |
25.0 |
73.0 |
|
LYF150-10 |
10.5 |
25.0 |
19.0 |
36.0 |
30.0 |
80.0 |
|
LYF150-12 |
13.0 |
25.0 |
19.0 |
36.0 |
30.0 |
80.0 |
|
LYF150-16 |
17.0 |
25.0 |
19.0 |
36.0 |
30.0 |
80.0 |
|
LYF150-20 |
21.0 |
25.0 |
19.0 |
36.0 |
30.0 |
87.0 |
|
LYF185-10 |
10.5 |
27.0 |
21.0 |
39.0 |
35.0 |
86.0 |
|
LYF185-12 |
13.0 |
27.0 |
21.0 |
39.0 |
35.0 |
86.0 |
|
LYF185-16 |
17.0 |
27.0 |
21.0 |
39.0 |
35.0 |
86.0 |
|
LYF185-20 |
21.0 |
27.0 |
21.0 |
39.0 |
35.0 |
93.0 |
|
LYF240-10 |
10.5 |
30.0 |
24.0 |
44.0 |
35.0 |
95.0 |
|
LYF240-12 |
13.0 |
30.0 |
24.0 |
44.0 |
35.0 |
95.0 |
|
LYF240-16 |
17.0 |
30.0 |
24.0 |
44.0 |
35.0 |
95.0 |
|
LYF240-20 |
21.0 |
30.0 |
24.0 |
44.0 |
35.0 |
95.0 |
|
LYF300-10 |
10.5 |
32.0 |
26.0 |
47.0 |
42.0 |
114.0 |
|
LYF300-12 |
13.0 |
32.0 |
26.0 |
47.0 |
42.0 |
114.0 |
|
LYF300-16 |
17.0 |
32.0 |
26.0 |
47.0 |
42.0 |
114.0 |
|
LYF300-20 |
21.0 |
32.0 |
26.0 |
47.0 |
42.0 |
114.0 |
|
LYF300-24 |
26.0 |
32.0 |
26.0 |
47.0 |
42.0 |
114.0 |
|
LYF400-12 |
13.0 |
36.0 |
30.0 |
54.0 |
48.0 |
126.0 |
|
LYF400-16 |
17.0 |
36.0 |
30.0 |
54.0 |
48.0 |
126.0 |
|
LYF400-20 |
21.0 |
36.0 |
30.0 |
54.0 |
48.0 |
126.0 |
|
LYF400-24 |
26.0 |
36.0 |
30.0 |
54.0 |
48.0 |
126.0 |
|
LYF500-20 |
21.0 |
42.0 |
33.0 |
61.0 |
47.0 |
134.0 |
|
LYF500-24 |
26.0 |
42.0 |
33.0 |
61.0 |
47.0 |
134.0 |
|
LYF630-16 |
17.0 |
53.0 |
39.0 |
75.0 |
68.0 |
180.0 |
|
LYF630-20 |
21.0 |
53.0 |
39.0 |
75.0 |
68.0 |
180.0 |
|
LYF630-24 |
26.0 |
53.0 |
39.0 |
75.0 |
68.0 |
180.0 |
